USE:
This machine uses LDPE and LLDPE to produce casting stretch film, which widely used in packing area for building material, auto parts, hardware parts etc.
FEATURE:
DF-65*2 automatic stretch film co-extruder with following features: two screws, low noise, stable running, especially winding part is controlled by PLC program. The machine is equipped with extruder, traction part, leveling part, edge trimming, winding and finished roll automatic changing etc.
Optional Equipment:
1)Auto load 2)Auto dry hopper 3)Motorize net changer 4)Hydraulic net changer 5)Air shaft 6)gule pump
Main Technical Parameter:
|
Screw Diameter |
φ65mm*2 |
|
L/D |
30:1 |
|
T-die Width |
1250mm |
|
Finished Film Width |
1000mm |
|
Finished Film Thickness |
0.012-0.05mm |
|
Max. Extrusion Output |
100kg/h |
|
Main Motor Power |
18.5kw*2 |
|
Air Consumption |
3m3/min |
|
Water Consumption |
0.5m3/h |
|
Total Power |
92kw |
|
Power Supply |
380/3/4/50(Volt/Ph/Line/Hz) |
|
Machine Size |
9000mm/2350mm/2400mm |
