This machine is suitable for slitting and rewinding such various roll materials as BOPP, PET, CPP, CPE, PVC, aluminum foil and paper, etc. and can cut edge, separate and cut material according to different requirements during production.
| Type | LFQ-700A | LFQ-1100A | LFQ-1300A |
| Max.Width of Mother Roll | 700mm | 1000mm | 1300mm |
| MAX.Diameter of Mother Roll | Φ600mm | Φ600mm | Φ600mm |
| Width of Final Roll | 30-600mm | 30-600mm | 30-600mm |
| Slitting and Rewinging Speed | 5-160m/min | 5-160m/min | 5-160m/min |
| Tolerance of EPC | <±0.5mm | <±0.5mm | <±0.5mm |
| Total Power | 2.7kw | 3.5kw | 3.5kw |
| Weight of Machine | 1200kg | 1500kg | 1800kg |
| Overall Dimension | 2000*1100*1400mm | 2300*1100*1400mm | 2600*1100*1400mm |
