SJ-C90,100,110,120Waste Plastics Recycling Machine is used for recycling of the used and waste plastic materials.It equipped with automatic constant temperature,clectric changing filter nets.It also can pelletize the croushing material after fitting with a loader.The cutting machine adopts speed regulating motor. which can cut the matcrial according to the feeding speed of the extruder. With such features as high output,low noise,stable performance and easy operation.It is a more ideal waste plastic film regenerative.pelletizer.
Main Technical Variables :
| model | SJ-90 | SJ-100 | SJ-110 | SJ-120 |
| Diameter of ScrewStem | 85mm | 95mm | 105mm | 110mm |
| Major Diameter Ratio of Screw Stem | 20:1-22:1(L/D) | 20:1-22:1(L/D) | 20:1-22:1(L/D) | 20:1-22:1(L/D) |
| Rationl Speed of Screw | 10-110rpm | 10-110rpm | 10-110rpm | 10-110rpm |
| Main Motor Power | 22kw | 30kw | 30kw | 37kw |
| Output | 60kg/h | 90kg/h | 110kg/h | 130kg/h |
| Machine Weight | 2t | 2.1t | 2.2t | 2.5t |
| Overail Dimensions(LxWxH) | 5800 x 1500 x 1100 | 5900 x 1300 x 1200 | 6000 x 1350 x 1300 | 6200 x 1400 x 1350 |
